Reliable Gelatinization Tank for Breweries
We are Wenzhou Jinggong Machinery Equipment Co., Ltd. We have made beer equipment for 35 years. Our factory covers 25,000 square meters. We have 68 employees. Our R&D team has 8 people. They focus on mashing systems and fermentation vessels. The gelatinization tank is the first step in beer brewing. It heats rice and starch. We have worked with big brands like Heineken, Budweiser, and Carlsberg. In China, we serve Snow, Yanjing, Pearl River, and Qiandaohu Beer. They choose us because our large brewing equipment is very stable. We control quality strictly. We use fully automatic machines. We have ISO9001 certification. We do 100% inspection before shipping. You can also ask a third party to check. We support that. Our large brewing equipment is non-standard and custom-made. So we cannot offer free samples. But custom samples take 15 to 30 days. You can mix different colors or models in one order. Minimum order is 1 unit. Standard payment is 30% deposit and 70% balance. We accept RMB and USD. Other currencies are negotiable. We follow local environmental rules. You can trust us.
Strong Stainless Steel Build with Good Insulation
The inner shell of our large brewing equipment is SUS304 stainless steel. We use steam for heating. The heating method is a coil jacket. This jacket can hold 3 bar of pressure. The heating speed is 1 to 1.5 degrees per minute. We use aluminum silicate fiber blankets for insulation. The agitator is at the bottom of the tank. Agitator speed is 28 to 32 rpm. You can adjust the speed. There is a steam outlet pipe on top. The pipe diameter is 450 mm. We add a condensate collector on the pipe. We also install a liquid level pressure probe. This probe shows the liquid level. It also controls the empty level. The temperature sensor can measure from -10°C to 150°C. The inner surface finish is ≤0.6um. There is a DN500 quick-opening manhole with a sight glass on top. There is also a sight glass light using DC24V. The manhole has an open-cover detection function. An indicator light shows the status. Cleaning uses a standard spray ball. The outlet is horn-shaped.
Technical Specifications of Our Gelatinization Tank
|
Parameter |
Value |
|
Material (inner shell) |
SUS304 stainless steel |
|
Heating method |
Steam coil jacket |
|
Jacket pressure resistance |
3 bar |
|
Heating rate |
1 – 1.5 °C per minute |
|
Insulation material |
Aluminum silicate fiber blanket |
|
Agitator speed |
28 – 32 rpm (adjustable) |
|
Steam outlet pipe diameter |
450 mm |
|
Temperature sensor range |
-10°C to +150°C |
|
Inner surface roughness |
≤0.6 μm |
|
Manhole size |
DN500 with sight glass |
|
Light voltage |
DC24V |
Service and Delivery You Can Count On
We offer a 1-year warranty. If the goods arrive damaged, we send new ones for free. We have a dedicated after-sales team. Before the sale, we ask about your needs. Then we give you a equipment plan and price. During the sale, we supervise production and ensure quality. After the sale, we help you solve problems. When we make the gelatinization tank, we follow a strict schedule. We keep enough spare parts. The production cycle is 30 to 45 days. During production, we send you photos or videos. So you can see the progress. We use fumigation-free wooden cases for packaging. We add plastic film and cloth outside. Shipping supports FOB and EXW. The gelatinization tank is the first step for many large breweries. We made similar tanks for Budweiser and Heineken. So they trust our design and welding. If you want a stable gelatinization system, we can help you.
