For Brewpubs, Hotels, and Small Workshops

Micro brewery equipment is a general name. We have made it into a standard series. The sizes go from 100 liters to 1000 liters. This set is good for a brewpub, hotel, restaurant, or small brewing workshop. Its features are small space, simple operation, and high beer quality. Many brewpubs start with our product. You can place it in a small room and still make great beer.

Flexible Configurations and Clean Build

Our standard micro brewery equipment includes a mash tun, lauter tun, boiling and whirlpool kettle, glycol tank, and fermenters. You can combine the mash and boiling into one pot. Or you can keep them separate. It depends on your budget and space. You can also combine the lauter and whirlpool into one tank. We call it a 2-vessel, 3-vessel, or 4-vessel system. You pick what fits you. All parts are SUS304 stainless steel. The inside is polished to ≤0.6μm roughness. Heating can be electric or steam. Electric heating is good if you have no steam source. We give stainless steel heating tubes with enough power. Steam heating is cheaper to run if you have a boiler. The fermenters come with cooling jackets. You can connect them to a glycol chiller. The temperature control accuracy is ±0.5 degrees. We offer semi-automatic and full-automatic controls. The semi-automatic system uses manual valves and buttons. The full-automatic system uses a touch screen and PLC. You can set a mashing temperature curve, boiling time, and fermentation temperature. The system does the work for you. It also records data for each batch. This product is easy to learn.

29- 2

Proven Design and Complete Service

We have worked with many craft brands. Some well-known brewpubs in China started with our 300L or 500L micro brewery equipment. Later they opened more locations and bought again from us. Our R&D team has 8 people. They often visit customers to see how the equipment works. They keep improving small details. For example, they made the lauter filter plate easier to clean. They changed the boiler heater to reduce burning. The smallest order is 1 set. You can mix different colors for fermenters. Payment is 30% deposit and 70% balance. We accept RMB and USD. No free samples. Custom sample time is 15 to 30 days. Production takes 30 to 45 days. We send photos and videos. Packaging is a fumigation-free wooden box. Shipment is FOB or EXW. The warranty is 1 year. Free replacement for shipping damage. We have a special person for after-sales service. Before you buy, we learn about your budget, space, and target output. We then make a plan and drawings. During production, we follow the schedule strictly. After delivery, we send an engineer to install and debug your product. We also train your brewer. We give recipe advice and remote troubleshooting.

29-

Key Technical Data

Parameter	Details
Batch size range	100 to 1000 liters
Configurations	2-vessel, 3-vessel, or 4-vessel
Material	SUS304
Inner roughness (kettles)	≤0.6μm
Heating options	Electric or steam
Fermenter cooling jackets	Yes, for glycol or ice water
Temperature accuracy	±0.5°C
Control options	Semi-automatic or full-automatic (PLC+touch screen)
Minimum order	1 set
Custom sample lead time	15 to 30 days
Production time	30 to 45 days
Payment terms	30% deposit, 70% balance
Warranty	1 year
